Three Phase Heater Cutoff Switch 16A-35A BW-HC25 Thermal Disconnect Switch

Name: Three Phase Heater Cutoff Switch 16A35A BWHC25 Thermal Disconnect Switch
Brand: HCET
Price: 1 USD

China Three Phase Heater Cutoff Switch 16A-35A BW-HC25 Thermal Disconnect Switch wholesale

Brand Name : HCET

Model Number : HC25

Certification : ROHS

Place of Origin : China

MOQ : 1000

Price : please contact us

Payment Terms : T/T

Supply Ability : 10000000 pcs per month

Delivery Time : 5-7 work days

Packaging Details : 2000 pcs per carton

Product name : HC25 thermal cutoff switch

Material : metal case

Temperature range : 70℃~160C

Tolerance : ±5℃,±8℃

Voltage : 250V

Current : 16-40A

Application : High Power Motor

Contact Now

Three Phase Bimetal High Current Thermal Protector Switch Cutoff Protector 16A-35A BW-HC25

Key Specifications

Product Name	HC25 thermal cutoff switch
Material	Metal case
Temperature Range	70℃~160℃
Tolerance	±5℃,±8℃
Voltage	250V
Current	16-40A
Application	High Power Motor

Product Overview

The BW-HC25 Three-Phase High Current Thermal Protector is engineered for extreme environments, delivering reliable overload protection for pumps, industrial motors, transformers, and high-power equipment (up to 35A). With precision bimetal technology and epoxy-sealed construction, it ensures stable performance in wet, oily, or dusty conditions while maintaining ultra-low internal resistance for energy efficiency.

Pre-calibrated temperature ranges (70°C-160°C ±5°C/±8°C) eliminate field adjustments, making it a plug-and-play safety solution for global industrial applications.

Key Features

Heavy-Duty Protection Handles 16A/25A/35A loads at 250V AC (50/60Hz) for motors, pumps, and transformers.
Environmental Resilience IP67-equivalent epoxy sealing resists water, oil, dust, and mechanical stress.
Precision Temperature Control Pure bimetal design minimizes current interference, with preset calibration (±5°C accuracy).
Fail-Safe Structure Closed casing prevents contamination while insulated terminals ensure operator safety.

Electrical Characteristics

Temperature Range	70℃~160℃ (Customizable temperature, please contact us)
Temperature Tolerance	±5℃, ±8℃
Electrical Specifications	250V AC 50HZ/60HZ, 16A,25A,35A

Dimension Size

Three Phase Heater Cutoff Switch 16A-35A BW-HC25 Thermal Disconnect Switch

Product Detail

Application
